| Picture
Tube |
15" (13.8"
diagonal viewable image), 0.24mm aperture grille pitch; FD
Trinitron® pure flat tube, invar shadow mask. |
| Max. Resolution |
1024 x 768@85Hz |
| Scanning
Frequencies |
Horizontal : 30 to
70 KHz
Vertical : 50 to 160 Hz |
| Max. Video input
Bandwidth |
95 MHz |
| Display
Area* |
Factory Setting:
approx. 300 mm x 225 mm
Active Area: approx. 325 mm x 242 mm |
| Input Signals |
Video: Analog 0.7 V
Sync: Digital 3.3 V (pos./neg. separate) |
| Input
Connector |
15-pin D-sub Type |
| Display Colors* |
Analog input; unlimited colors |
| Power
Source |
90 - 264 VAC (47 -
63 Hz, single phase, full-range) |
| Front Panel
Controls |
Power, Select, Adjust+, Adjust- |
| EasyScreen
OSD Controls |
Brightness,
Contrast, H/V Size, H/V Position, Pincushion, Pincushion balance,
Trapezoid, Parallelogram, Tilt, H/V Moire, Color, H/V Linearity,
Top/Bottom Corner, Management (Power saver, Mode display, Serial
number), Factory Reset, 3D (optional). |
| Audio |
Built-in speaker 2.5W x 2 (optional) |
| 3D
Kit |
3D Module
(optional): 56.8K carrier, IR wireless transmitter;
3D Glasses (optional): 56.8K carrier, IR wireless receiver. |
| Power Consumption |
85 watts (max.) |
|
Power Management
|
EPA/Energy Star,
NUTEK/TCO compliant, VESA DPMS signaling method |
| PnP Compatibility |
VESA DDC 1 & 2B standards
compliant |
| Safety
Regulations |
UL, DHHS, CSA, TÜV,
NORDIC (NEMKO, SEMKO, FIMKO, DEMKO), CB Report |
| EMI |
FCC class B, CE DOC, VCCI
Class2, CISPR 22, VCCI C-tick, CCIB, BCIQ, RFS43 |
| Ergonomics |
ISO 9241-3 / 7/ 8,
MPR II, TCO 95 ( optional ) |
| Monitor Dimension |
357mm(W) x362mm(H) x 373mm(D) |
| Net
Weight |
13 kg |
| Ambient
Temperature |
Operating: 0°C to 40°C
Storage: -20°C to 65°C |
| Humidity |
Operating: 20% to
95%
Storage: 10% to 95% |
|
|
