| Picture
Panel |
17 inch diagonal
viewable screen
TFT (thin film transistor) active matrix, color liquid crystal
display, RGB interface. |
| Max. Resolution |
1280 x 1024 (SXGA) |
| Display
area (H x V) |
337.92mm (H) x
270.34mm (V ) |
| View
angle |
100°Vertical / 120°Horizontal |
Input
signals
|
Horizontal: 31.47 to 64 kHz
Vertical: 56 to 75 Hz
Video: 0.7 Vp-p
Sync: TTL level
|
| USB (Option) |
Optional USB hub with
4 downstreams and 1 upstream |
| Max.
video input bandwidth |
108 MHz
|
| Display color* |
16.7M colors |
| Luminance |
250 cd/m2 |
| Contrast ratio |
300:1 |
| Response
time |
50 msec |
| Pixel Pitch |
0.264 mm (H)x 0.264 mm (V) |
| Front
panel controls |
Menu, Adjust +,
Adjust -, POWER |
| OSD menu controls |
Auto Adjustment ,Brightness ,Contrast
,Color, H-position, V-position, Clock, OSD position ,Input type
Multi-Languages, Factory Preset, Cancel, Save & Exit |
| Input
connectors |
15-pin D-sub Type, Adapter(DC 12V,6.5A) , S-Video ,DVI
|
|
Power source
|
100 ~ 240 VAC, 50-60
Hz, built-in power supply |
| Power
consumption |
40 watts (max.) |
| Power saving |
VESA DPMS standard, EPA/Energy Star
compliant |
| PnP
compatibility |
VESA DDC 2B
standards compliant |
| Regulations |
UL, CSA,CE/ TUV, FCC-classB,
TCO99(optional) |
| Dimension |
450mm (W) x 462mm
(H) x 214mm (D) |
| Net weight |
6.9 kg |
| Ambient
Temperature |
Operating
:10°C to 40°C
Storage : -10°C to 60°C |
| Humidity |
Storage : 15% to 90%
RH |
