| Picture
Panel |
18.1 inch diagonal
viewable screen
TFT(thin film transistor) active matrix, color liquid crystal
display, RGB interface. |
| Max. Resolution |
1280 x 1024 (SXGA) |
| Display
area (H x V) |
359mm (H) x 287mm (V
) |
| View
angle |
160°Vertical / 160°Horizontal |
Input
signals
|
Horizontal: 31.47 to
64 kHz
Vertical: 56 to 75 Hz
Analog RGB: 0.7 Vp-p
Sync:TTL level |
| Max. video input
bandwidth |
108 MHz |
| Display
color* |
16.7M
colors |
| Luminance |
200 cd/m2 |
| Contrast
ratio |
300:1 |
| Response time |
50 msec |
| Pixel
Pitch |
0.2805 mm (H)x
0.2805 mm (V) |
| Front panel
controls |
Menu, Adjust +, Adjust -, POWER |
| OSD
menu controls |
Auto Adjustment
,Brightness ,Contrast ,Color, H-position, V-position, Clock, OSD
position ,Input type Multi-Languages, Factory Preset, Cancel, Save
& Exit |
| Input connectors |
15-pin D-sub Type, Adapter(DC
12V,6.5A) , S-Video ,DVI |
|
Power source
|
100
~ 240 VAC, 50-60 Hz, built-in power supply |
| Power consumption |
45 watts (max.) |
| Power
saving |
VESA DPMS standard,
EPA/Energy Star compliant |
| PnP
compatibility |
VESA DDC 1& 2B standards compliant |
| Safety
standards |
UL, CSA, TÜV/GS |
| EMI |
FCC Class B, CISPR- 22, VCCI-II, CE |
| Ergonomics |
ISO9241-3/ 7/ 8,
TCO99 (optional) |
| Dimension |
450mm (W) x 462mm (H) x 214mm (D) |
| Net
weight |
7.9 kg |
| Ambient
Temperature |
Operating :10°C to 40°C
Storage : -10°C to 60°C |
| Humidity |
Storage
: 10% to 95% RH |
|
|
