Picture Panel |
15-inch diagonal viewable
screen
a-Si TFT (thin film transistor) active matrix, color liquid crystal display. |
| Max. Resolution |
1024 x 768 (XGA) |
| Display
area (H x V) |
304.1mm (H) x 228.1mm (V ) |
| View angle |
100¢X Vertical / 120¢X Horizontal |
Input
signals
|
Horizontal: 31 to 69 kHz
Vertical: 56 to 75 Hz
Analog RGB: 0.7 Vp-p
Sync: 5V (pos./net. Separate) |
| Max. video input bandwidth |
80 MHz |
| Display
color* |
16.7M colors |
| Luminance |
250 cd/m2 (Typ.) |
| Contrast
ratio |
350:1(typ.) |
| Response time |
40 msec (Typ.) / (13 msec rising) |
| Pixel
Pitch |
0.297 mm (H) x 0.297 mm (V ) |
| OSD menu
controls |
Auto Adjustment, Brightness,
Contrast, Color, H-position, V-position, Clock, OSD position,
Multi-Languages, Factory Preset, Cancel, Save & Exit |
| Input connectors |
15-pin D-sub Type, DC Jack, Audio Jack |
| Power consumption |
25 watts (max.) |
| Power
saving |
VESA DPMS standard, |
| PnP compatibility |
VESA DDC 1& 2B standards compliant |
| Safety
standards |
UL, CSA, TUV/GS |
| EMI |
FCC Class B, CE (CISPR- 22), BSMI |
|
Ergonomics |
ISO9241-3/ 7/ 8, TCO99 |
| Dimension |
360mm (W) x 373mm (H) x 173mm (D) |
| Net
weight |
3.2 kg |
| Ambient
Temperature |
Operating: 0¢XC to 40¢XC
Storage: -10¢XC to 65¢XC |
| Humidity
|
Operating:
25% to 90%
Storage: 0% to 90% RH |
| Preset Mode |
VGA 640x350 @ 70Hz
VGA 720x400 @ 70Hz
VGA 640x480 @ 60/67/72/75Hz
SVGA 800x600 @ 56/60/72/75Hz
SVGA 832x624 @ 74.6Hz(Mac)
XGA 1024x768 @ 60/70/75Hz |
