Picture Panel |
17-inch diagonal viewable screen
a-Si TFT (thin film transistor) active matrix, color liquid crystal display. |
|
Max. Resolution |
1280 x 1024 (SXGA) |
|
Display area (H x V) |
337.9 mm (H) x 270.3 mm (V ) |
|
View angle |
140¢X Vertical / 140¢X Horizontal
|
Input signals
|
Horizontal: 31 to 80 kHz
Vertical: 56 to 75 Hz
Analog RGB: 0.7 Vp-p
Sync: 5V (pos./net. Separate) |
|
Max. video input bandwidth |
135 MHz |
|
Display color* |
16.7M colors |
|
Luminance |
260 cd/m2 (Typ.) |
|
Contrast ratio |
450:1(typ.) |
|
Response time |
16 msec |
|
Pixel Pitch |
0.264 mm (H) x 0.264 mm (V ) |
|
OSD menu controls |
Analog: Auto Adjustment
,Brightness ,Contrast, Clock, Clock Phase, Color, Language, OSD Adjust,
Input Select, Hue, Flash Tone, Volume, Mute
Digital: Brightness, Color, Language, OSD Adjust, Input Select, Hue, Flash
Tone |
|
Input connectors |
15-pin D-sub Type, |
|
Voltage Rating |
100-240 Vac |
|
Power consumption |
35 watts (max.) |
|
Power saving |
VESA DPMS standard, |
|
PnP compatibility |
VESA DDC 1& 2B standards compliant |
|
Audio System |
Speaker 2ch x 2w max, Earphone
Jack |
|
Safety standards |
CULus,ISO13406-2, TO99, SEMKO,
DEMKO, TUV/GS |
|
EMI |
FCC Class B, CE, EN55022-B |
|
Dimension |
372mm (W) x 395.5mm (H) x 185mm
(D) |
|
Net weight |
3.8 kg |
|
Ambient Temperature |
Operating : 10¢XC to 35¢XC
Storage : -05¢XC to 45¢XC |
|
Humidity |
Storage : 30% to 80% RH |
|
