Picture Panel |
15-inch diagonal viewable
screen TFT (thin film transistor) active matrix, color liquid crystal
display. |
| Resolution |
1024 x 768 (XGA) |
| Display
area (H x V) |
304.1mm (H) x 228.1mm (V ) |
| View angle |
100°Vertical / 120°Horizontal |
| Input
signals |
Horizontal: 31.47 to 60.24
kHz
Vertical: 56 to 75 Hz
Analog RGB: 0.7 Vp-p
Sync: 5V (pos./net. Separate) |
| Max. video input bandwidth |
80 MHz |
| Display
color* |
16.7M colors |
| Signal System |
Analog RGB |
| Luminance |
250 cd/m2 (typ.) |
| Contrast
ratio |
400:1 (typ.) |
| Response time (tr+tf) |
8 + 22 msec |
| Pixel
Pitch |
0.297 mm (H)x 0.297 mm (V) |
| Front panel controls |
Menu, Adjust +, Adjust -, POWER |
| OSD menu
controls |
Auto Adjust, Brightness,
Auto Position, Contrast, Color, H/ V-position, Clock, phase, OSD off time,
Languages, Factory Preset, Cancel, Save & Exit |
| Input connectors |
15-pin D-sub Type, Adapter (DC
12V 4A) |
| Power
source |
100 ~ 240
VAC, 50-60 Hz, |
| Power consumption |
18 watts (max.) |
| Power
saving |
VESA DPMS standard,
EPA/Energy Star compliant |
| PnP compatibility |
VESA DDC 1& 2B standards compliant |
| Safety
standards |
UL, CSA, TÜV/GS, |
| EMI |
FCC Class B, VCCI-II, CE( CISPR-22), BSMI |
|
Ergonomics |
ISO13406-2, TCO03 |
| Dimension |
156.5mm (W) x 334mm (H) x345.6mm
(D) |
| Net
weight |
3.5 kg |
| Ambient Temperature |
Operating :10°C to 40°C
Storage : -10°C to 60°C |
|
Humidity |
Storage : 15% to 90% RH |
|
