| Resolution |
1024 x 768 (XGA) |
| Display
area (H x V) |
304.1mm (H) x
228.1mm (V ) |
| View
angle |
160°Vertical / 160°Horizontal |
| Input
signals |
Horizontal: 31.47 to
60.24 kHz
Vertical: 56 to 75 Hz
Analog RGB: 0.7 Vp-p
Sync: 5V (pos./net. Separate) |
| Max.
video input bandwidth |
80 MHz |
| Display
color* |
16.7 M colors |
| Luminance |
250 cd/m2 |
| Contrast
ratio |
350:1 |
| Response
time |
40 msec |
| Pixel
Pitch |
0.297 mm (H)x 0.297
mm (V) |
| Front panel
controls |
Menu, Adjust +, Adjust -, POWER |
| OSD
menu controls |
Auto Adjustment,
Brightness, Contrast, Color, H-position, V-position, Clock phase,
OSD position, Multi-Languages, Factory Preset, Cancel, Save &
Exit |
| Audio |
Built-in microphone
and speaker |
| Input
connectors |
15-pin
D-sub Type, AC/IN,S-Video connector |
|
Power source
|
100 ~ 240 VAC, 50-60
Hz, built-in power supply |
| Power
consumption |
35 watts (max.) |
| Power
saving |
VESA DPMS standard,
EPA/Energy Star compliant |
| PnP
compatibility |
VESA DDC 1& 2B
standards compliant |
| Safety
standards |
UL, CSA, TÜV/GS,
NORDIC (NEMKO, SEMKO, FIMKO, DEMKO) |
| EMI |
FCC Class B, CISPR-
22, VCCI-II, CE |
| Ergonomics |
ISO9241-3/7/8,
TCO99(optional) |
| Dimension |
389mm (W) x 390mm
(H) x 220mm (D) |
| Net
weight |
5.1 kg |
| Ambient
Temperature |
Operating
:5°C to 45°C
Storage : -20°C to 60°C |
| Humidity |
Storage
: 10% to 95% RH |
| Audio |
Build-in microphone
and speakers 2W x 2 |
| Pivotable
Enabled |
90° |
| Wall-mountable
Function |
Wall-mountable
capability compliant with VESA standard. |
