| Picture Panel
|
17.1 inch diagonal viewable
screen
TFT(thin film transistor) active matrix, color liquid crystal display, RGB
interface. |
| Max.
Resolution |
1280 x 1024 (SXGA) |
|
Display area (H x V) |
337.9mm (H) x
270.3mm (V ) |
| View angle |
100° / 120° |
Input signals
|
Horizontal:
31.47 to 64 kHz
Vertical: 56 to 75 Hz
Analog RGB: 0.7 Vp-p
Sync:5V (pos./net. Separate) |
| Max. video
input bandwidth |
108 MHz |
|
Display color* |
16.7M colors |
| Luminance |
250 cd/m2(typ.) |
|
Contrast ratio |
300:1(typ.) |
| Response time |
15 msec |
|
Pixel Pitch |
0.2805 mm (H)x
0.2805 mm (V) |
| Front panel
controls |
Menu, Adjust +, Adjust -, POWER |
|
OSD menu controls |
Auto Adjustment
,Brightness ,Contrast ,Color, H-position, V-position, Clock, OSD position
,Input type Multi-Languages, Factory Preset, Cancel, Save & Exit |
| Input
connectors |
15-pin D-sub Type, Adapter(DC
12V,6.5A) |
|
Power source |
100 ~ 240 VAC, 50-60 Hz, built-in power supply |
| Power
consumption |
55 watts (max.) |
|
Power saving |
VESA DPMS
standard, EPA/Energy Star compliant |
| PnP
compatibility |
VESA DDC 1& 2B standards compliant |
|
Safety standards |
UL, CSA, TÜV/GS |
| EMI |
FCC Class B, CISPR- 22, VCCI-II,
CE |
|
Ergonomics |
ISO13406-2,
TCO99 (optional) |
| Dimension |
450mm (W) x 462mm (H) x 214mm (D) |
|
Net weight |
6.8 kg |
| Ambient
Temperature |
Operating :10°C to 40°C
Storage : -10°C to 60°C |
|
Humidity |
Storage : 15% to 90% RH |
|
