Picture Panel |
15-inch diagonal viewable screen.
TFT (thin film transistor) active matrix, color liquid crystal display.
|
|
Resolution |
1024
x 768 (XGA) |
|
Display area (H x V) |
304.1mm (H) x 228.1mm (V) |
|
View angle |
100o Vertical / 120o Horizontal |
Input signals
(Analog / DVI) |
Horizontal: 31.47 to 60.24 kHz,
Vertical: 56 to 75 Hz
Analog RGB: 0.7 Vp-p , Sync: 5V (pos./net. Separate)
TV-video (Separated Y,C),NTSC(3.58M),PAL(4.43M)
TV-video (CVBS) ,NTSC(3.58M),PAL(4.43M)
|
|
Max. video input bandwidth |
80 MHz |
|
Display color* |
Simulation to true colors |
|
Luminance |
250
cd/m2 (typ.) |
|
Contrast ratio |
350:1 (typ.) |
|
Response time |
15
msec |
|
Pixel Pitch |
0.297 mm (H) x 0.297 mm (V) |
|
Front panel controls |
Menu, Adjust +, Adjust -, POWER |
|
OSD menu controls |
Auto Adjustment ,Brightness
,Contrast ,Color, H-position, V-position, Clock, OSD position ,Input type
Languages, Factory Preset, Cancel, Save & Exit |
|
Input connectors |
15-pin D-sub Type,
Adapter(12V,1.5A), Microphone ,Speakers ,S-Video ,Composite ,DVI |
|
Power source |
100 ~ 240 VAC, 50-60 Hz |
|
Power consumption |
35
watts (max.) |
|
Power saving |
VESA DPMS standard, EPA/Energy
Star compliant |
|
PnP compatibility |
VESA
DDC 1& 2B standards compliant |
|
Safety standards |
CUL, TUV/GS |
|
EMI |
FCC
Class B, VCCI-II, CE, BSMI, CCEE |
|
Ergonomics |
ISO9241-3/ 7/ 8, TCO99 (optional) |
|
Dimension |
389mm (W) x 387mm (H) x 173mm (D) |
|
Net weight |
5 kg |
|
Ambient Temperature |
Operating :0° c to 40° c
Storage : :-10° c to 65° c |
|
Humidity |
Operating : 25% to 90% ,
Storage : 0% to 90% RH |
|
Preset Mode |
VGA 640x350 @ 70Hz
VGA 720x400 @ 70Hz
VGA 640x480 @ 60/67/72/75Hz
SVGA 800x600 @ 56/60/72/75Hz
SVGA 832x624 @ 74.6Hz(Mac)
XGA 1024x768 @ 60/70/75Hz
|
|
