PROCESSORS

462 pin Socket A supports the

AMD? Athlon (K7) processors up to 1.2GHz(100MHz FSB)

AMD? Duron processors up to 850MHz

Full series of Athlon processors including the newest Duron and Thunderbird processors

CHIPSET

VIA? VT8363 (NB) & VT82C686A/B (SB)

Support AGP 2.0 specification (4X)

Super I/O - Integrated in VT82C686A (SB)

System Hardware Monitor: Integrated in VT82C686A (SB)

AC97 Audio Codec: Avance ALC100 (RealTek)

Compliant with AC97 2.1 specification

SYSTEM BIOS

Three 168-pin DIMMs sockets for 3.3V SDRAM (Ready for PC100, PC133)

Maximum: 1.5GB

MEMORY

Award 2MB Flash EEPROM

Supports Plug and Play 1.0A, AMP 1.2, Multi Boot, DMI

Support for ACPI revision 1.0 specification

I/O INTERFACE

Supports Plug and Play function

PS/2 keyboard and PS/2 mouse connectors

Four USB Ports (Two USB Connectors as header onboard)

One - EPP/ECP mode parallel port

Two - 16550 high-speed serial I/O ports

Audio Ports (Line-in, Line-out, Mic-in, CD-in and game port)

Dual PCI IDE interfaces - support four IDE devices (PIO mode 4, DMA Mode 2, Ultra DMA 66/100)

Supports 360K~2.88M Byte, 3 Mode FDDs or LS120

ATX Power Supply Connector

Ports, Headers and Others:

IrDA header

Extra USB Header

Green, HDD, Power indicator LED headers

CPU and Case Fan headers

LAN Card Wake Up / Modem Ring Wake-Up headers

RTC & BATTERY

VT82C686A included 256 bytes of CMOS SRAM

With CMOS hardware clear jumper

EXPANSION SLOTS

5 PCI slots, 1 AGP slot, 1 AMR slot

FORM FACTOR

ATX (304mm*220mm)
