PROCESSORS

462 pin Socket A supports the

AMD? Athlon (K7) processors up to 1.2GHz(100MHz FSB) and 1.2CGHz(133MHz FSB)

AMD? Duron processors up to 850MHz

Full series of Athlon processors including the newest Duron and Thunderbird processors

CHIPSET

VIA? VT8363 (NB) & VT82C686A/B (SB)

Support AGP 2.0 specification (4X)

Super I/O - Integrated in VT82C686A (SB)

System Hardware Monitor: Integrated in VT82C686A (SB)

LAN: RealTek 8139C

AC97 Audio Codec: Avance ALC100 (RealTek)

Compliant with AC97 2.1 specification

SYSTEM BIOS

Two 168-pin DIMMs sockets for 3.3V SDRAM (Ready for PC100, PC133)

Maximum: 1.0GB

MEMORY

Award BIOS with 4MB Flash ROM in Firmwave Hub (FWH)

Supports Plug and Play 1.0a, AMP 1.2, Multi Boot, DMI

Support for ACPI revision 1.0A specification

I/O INTERFACE

Supports Plug and Play function

PS/2 keyboard and PS/2 mouse connectors

Four USB Ports (Two USB Connectors as header onboard)

One - EPP/ECP mode parallel port

Two - 16550 high-speed serial I/O ports

Audio Ports (Line-in, Line-out, Mic-in, CD-in and game port)

Dual PCI IDE interfaces - support four IDE devices (PIO mode 4, DMA Mode 2, Ultra DMA 66/100)

Supports 360K~2.88M Byte, 3 Mode FDDs or LS120

LAN Header

ATX Power Supply Connector

Ports, Headers and Others:

IrDA header

Extra IR/KB/Mouse header

Extra MIC/Line-out header

Green, HDD, Power indicator LED headers

CPU and Case Fan headers

Modem Ring Wake-Up header

RTC & BATTERY

VT82C686A included 256 bytes of CMOS SRAM

With CMOS hardware clear jumper

EXPANSION SLOTS

2 PCI slots, 1 AGP slot, 1 AMR slot

FORM FACTOR

microATX (244mm*220mm)
