PROCESSORS

Socket 370 supports the

FC-PGA Pentium® III series processors including the newest Tualatin CPU

Intel® Celeron™ FC-PGA II series processors

CHIPSET

VIA® VT82C694T & VT82C686B chipset

Support AGP 2.0 specification (4X)

Super I/O - Integrated in VT82C686B

System Hardware Monitor: Integrated in VT82C686B

AC97 Audio Codec

Compliant with AC97 2.1 specification

SYSTEM BIOS

Award 2Mb Flash EEPROM

Supports Plug and Play 1.0A, AMP 1.2, Multi Boot, DMI

Full Support for ACPI revision 1.0 specification

MEMORY

Two 168-pin DIMMs sockets for 3.3V SDRAM (Ready for PC133/PC100)

Maximum: 1GB

I/O INTERFACE

Supports Plug and Play function

PS/2 keyboard and PS/2 mouse connectors

Four USB Ports (Two USB Connectors as header onboard)

One - EPP/ECP mode parallel port

Two - 16550 high-speed serial I/O ports

Audio Ports (Line-in, Line-out, Mic-in, CD-in and game port)

Dual PCI IDE interfaces - support four IDE devices (PIO mode 4, DMA Mode 2, Ultra DMA 33/66/100)

Supports 360K~2.88M Byte, 3 Mode FDDs or LS120

ATX Power Supply Connector

Ports, Headers and Others:

IrDA Cable header

Front Panel IR/KB/Mouse header

HDD LED, ACPI MSG LED, Reset Switch, Power Switch headers

CPU and Case Fan headers

LAN Card Wake Up / Modem Ring Wake-Up headers

RTC & BATTERY

VT82C686B included 256 bytes of CMOS SRAM

With CMOS hardware clear jumper

EXPANSION SLOTS

3 PCI slots, 1 CNR or ISA slot, 1 AGP slot

FORM FACTOR & LAYERS

microATX (244mm x 220mm), 4 Layers
