Network (845G Max-L only)
* ICH4 Integrated LAN controller
* Intel 82562ET
- ACPI and APM supported
- Wake-On-LAN and WFM 2.0 supported
CPU
* Supports Socket 478 for Intel? Pentium 4 processor
* Supports 1.3 ~ 2.53GHz and up
Chipset
Intel? 845G (788 FC-BGA) Chipset
- AGP 4x slot (1.5V only)
- Integrated graphic controller
- Supports 100/133MHz FSB
- Supports 400/533MHz Intel NetBurst micro-architecture bus
Intel? ICH4 (421BGA) Chipset
- AC'97 2.2 interface
- 6 USB 2.0/1.1 ports
- 2 channel Ultra ATA/100 Bus Master IDE controller
- SMBus 2.0 support
- Integrated LAN controller
FSB
- Support 100/133MHz FSB
- Support 400/533MHz Intel NetBurst micro-architecture bus.
Main Memory
Three 184-pin DDR DIMM sockets
Supports 64 to 512MB technologies for x8 and x16 devices
Slots
* One AGP (Accelerated Graphics Port) 4x slot (1.5V only)
* Six PCI 2.2 32-bit Master PCI Bus slots (supports 3.3V/5V
PCI bus interface)
* One CNR (Communication Network Riser) slot
On-Board IDE
* An IDE controller on the ICH4 chipset provides IDE HDD/
CD-ROM with PIO, Bus Master and Ultra DMA 66/100
operation modes.
* Can connect up to 4 IDE devices
Audio
* ICH4 chip integrated
* AC'97 2.2 compliant
Video
* 845G Chipset Integrated graphic controller
- One DB 15-pin VGA connector is supplied for connection to a
VGA monitor.
Network
* ICH4 Integrated LAN controller (Optional, 845G Max-L only)
* Intel 82562ET
- ACPI and APM supported
- Wake-On-LAN and WFM 2.0 supported
On-Board Peripherals
On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M
and 2.88Mbytes
- 2 serial ports (COM A + COM B pin header), 1 VGA port
- 1 parallel port supports SPP/EPP/ECP mode
- 6 USB 2.0/1.1 ports (Rear * 2 / Front * 4)
- 1 Line-In/Line-Out/Mic-In/Game port
- 1 RJ45 connector (Optinal, For 845G Max-L only)
BIOS
* The mainboard BIOS provides "Plug & Play" BIOS which
detects the peripheral devices and expansion cards of the
board automatically.
* The mainboard provides a Desktop Management Interface
(DMI) function which records your mainboard specifications.
Dimension
30.5 cm(L) x 21.5 cm(W) ATX Form Factor
Mounting
6 mounting holes.
Special Functions
Bluetooth Function (Optinal, For 845G Max-L only)
Accessories
D-Bracket?2
(Optional, 845G Max-L, 845G Max-BL)
