ITEM

Support Socket 478 processors
Support Intel Willamette-478 1.5/1.6/1.7/1.8/1.9/2.0GHz
Support Intel Northwood-478 1.6/1.8/2.0/2.1/2.26/2.4/2.53GHz

400/533MHz FSB

2 Mbit firmware Hub
Licensed advanced Award (phoenix) BIOS
Support Plug and Play
Support ACPI and OS directed power management

Two PCI Master IDE ports support up to 4 IDE devices
Support ATA 33/66/100
One Floppy port support up to two 3.5' or 5.25' floppy drives
(360K/720K/1.2M/1.44M/2.88M)
Support LS-120 floppy disk drive and ZIP drive

2 high speed Serial Ports (16550 Fast UART Compatible)
1 Enhanced Parallel Port support EPP/ECP/SPP
4 USB support USB1.1(2 USB on back panel, 2 USB on front header with optional cable)
1 PS/2 keyboard port
1 PS/2 mouse port
1 Speaker+ 1 Line in+ 1 Mic (Optional)
1 Game port (Optional)
1 RJ45 port (Optional)
IrDA port support up to 115.2Kb/s transfer rate
All I/O ports can be enabled/disabled by BIOS setup

Provides AGP 4X interface
Support APG 4X (1.5v) card
Transfer rate up to 1GB/sec

AC'97 2.1 compliant
16-bit Stereo Codc
Upgradable to 6 channels audio with CNR card

PCI 2.2 Specification compliant
Support OS soft-off
Wakeup on LAN
Wake up on Modem
Power-on by keyboard password
Trend ChipAway Virus on Guard
Norton AntiVirus 2002
5 LEDs to indicate CPU/chipset, Memory, PCI peripherals, clockgen and graphics card status.

Support ACPI (Advance configration and power interface) and ODPM(OS Directed Power Management)
CPU temperature, System temperature, CPU fan speed,
Chassis fan speed, 8 System Voltages
Power Management
ACPI  v1.0 and APM Compliant
Support S0 (full-on) , S1 (power on suspend), S3 (suspend to RAM), S5 (soft-off) ACPI power status

On board Intel 10/100 Mbps LAN (Intel 82559 core built-in ICH2) (P2D/533-L Only)
