ITEM

Supports Intel® Pentium 4( Willamette ) socket 478 processors at 1.4/1.5/1.6/1.7/1.8/1.
9/2.0 GHz at 400 MHz FSB
Supports Intel® Pentium 4( Northwood ) socket 478 processors at 1.6A/1.8A/2.0A/2.2/
2.4 GHz at 400 MHz FSB

400MHz FSB

2 Mbit firmware Hub
Licensed advanced Award ( phoenix ) BIOS
Support Plug and Play
Support ACPI and OS directed power management

Two PCI Master IDE ports support up to 4 IDE devices
Support ATA 33/66/100
One Floppy port support up to two 3.5' or 5.25' floppy drives
( 360K/720K/1.2M/1.44M/2.88M )
Support LS-120 floppy disk drive and ZIP drive

2 high speed Serial Ports ( 16550 Fast UART Compatible )
1 Enhanced Parallel Port support EPP/ECP/SPP
6 USB support USB2.0 ( 2 on back panel,4 on front header with optional cable)
1 PS/2 keyboard port
1 PS/2 mouse port
1 Speaker+ 1 Line in+ 1 Mic ( Optional )
1 Game port ( Optional )
1 RJ45 port ( Optional )
IrDA port support up to 115.2Kb/S transfer rate
All I/O ports can be enabled/disabled by BIOS setup

AC' 97 2.2 Specification Compliant
Support S/PDIF output
Provides onboard Line-in Jack, Microphone-in Jack, Speaker-out Jack with onboard
amplifier and MIDI/Joystick Connector
AC'97 ( P7BL-A )

PCI 2.2 Specification compliant
Support OS soft-off
Wakeup on LAN
Wake up on Modem
Power-on by keyboard password
Trend ChipAway Virus on Guard
Norton AntiVirus™ 2002

Support ACPI ( Advance configration and power interface ) and ODPM ( OS Directed Power Management )
CPU temperature, System temperature, CPU fan speed,
Chassis fan speed, 8 System Voltages
Power Management
ACPI V1.0 and APM Compliant
Support S0 ( full-on ), S1 ( power on suspend ), S3 ( suspend to RAM ), S5 ( soft-off ) ACPI power status

Optional for P7BL-L
