Sound
        Blaster PCI512


        This product is available in Americas. |







      Introduction
        Sound Blaster PCI512 is the ultimate audio system for playing today's
        hottest games. As the industry's most affordable sound card with
        hardware support for EAX, the Sound Blaster PCI512 provides incredibly
        immersive audio with the powerful combination of hardware acceleration,
        multi-speaker support, and the widest compatibility with a wide variety
        of games and multimedia titles.
         EAX is the new audio platform by Creative with superior 3D positional
        sound and effects rendering that recreates real-life, multi-dimensional
        environments with unsurpassed realism. Featuring the same powerful audio
        processing chip used in the Sound Blaster Live!, the EMU10K1 provides
        on-board hardware acceleration so there is never a slowdown during
        gameplay.
         And, with support for two-, four-, and FourPointSurround speaker
        systems, the Sound Blaster PCI512 delivers the most accurate 3D
        positional audio currently available. You'll hear enemies creep up from
        behind and missiles scream overhead. Sounds will literally come from all
        corners of the room by adding realism and atmosphere to any audio
        source.
         Try the Sound Blaster PCI512 today. It's the difference between
        hearing your games and music, and actually experiencing them.

       |


      Features
        and Performance


          - Enjoy incredibly immersive 3D audio in real-time with
            award-winning EAX

           - Connect easily to FourPointSurround and stereo speakers with
            4-channel analog audio support

           - Take advantage today of the widest range of audio, game, and
            multimedia titles



        Audio Hardware Acceleration Delivers the Most Exciting Game Play
        Sound Blaster PCI512 features the most advanced audio DSP technology for
        the PC, the EMU10K1. With 32-bit, 48kHz digital signal processing and a
        patented 8-point interpolation, the EMU10K1 produces remarkably clear
        and precise audio fidelity. It is capable of accurately rendering 3D
        positional audio using only two or four speaker configurations. With
        on-board hardware acceleration, nothing impedes the action in today's
        most demanding games for even one, heart-stopping second.
         Industry's Best PC Compatibility
        Sound Blaster PCI512 is a snap to install with complete plug-and-play,
        Windows 95 and 98 compatibility. With the hardware acceleration of EAX,
        DirectSound and DirectSound 3D, Sound Blaster PCI 512 accurately
        produces high fidelity sound in virtually any audio application. And,
        with Sound Blaster PCI compatibility, you will be assured of support for
        the largest selection of existing MS-DOS® and
        Windows-based games and other titles. This is exactly what you'd expect
        from Creative, the leader in PC audio technology.
         Title Support Updates
        EAX is rapidly becoming the 3D audio standard, with support from top
        games like Unreal, Thief, Half-Life, Aliens VS Predator, Myth II, SHOGO,
        and many more. With new titles supporting EAX being released regularly,
        visit http://www.env-audio.com to find the latest in title support as
        well as updated drivers and information about the product.
         The Most Affordable EAX
        Imagine PC sound so realistic you can visualize what is making the
        sounds, where it is coming from, and the environment you're in. Its
        revolutionary technology creates true-to-life audio by immersing you in
        sounds so real that you will experience games, music and other audio
        applications rather than just hear them.


           |


      Product
        Specs




              | Feature |
              Description |


              | Synthesizer
                Chip |
              EMU
                10K1 |


              | Synthesizer
                Type |
              Wavetable
                (Scaleable PCI) |


              | Polyphony |
              64
                (8-point interpolation) |


              | ROM
                size |
              NA |


              | RAM
                size |
              Based
                on System RAM |


              | Sample
                Sets |
              2,
                4 and 8MB |


              | Synthesizer
                Effects |
              Reverb,
                Chorus, Flanger, Pitch Shifter, Distortion, etc |


              | MIDI
                Channels |
              48 |


              | Duplex
                Type |
              Full
                Duplex |


              | Max.
                Recording Depth |
              16-bit |


              | Max.
                Recording Rate |
              48
                KHz |


              | Max.
                Playback Depth |
              16-bit |


              | Max.
                Playback Rate |
              48
                KHz |


              | Signal-to-Noise
                Ratio |
              >96
                dB |


              | Soundfont
                Support |
              Yes |


              | Built-in
                Amplifier |
              NA |


              | Windows
                2000 |
              Yes |


              | Windows
                98 |
              Yes |


              | Windows
                95 |
              Yes |


              | Windows
                NT 4.0 |
              Yes |


              | General
                MIDI |
              Yes |


              | MPC3 |
              Yes |


              | Plug
                & Play |
              Yes |


              | Sound
                Blaster PCI |
              Yes |


              | EAX
                Support |
              Yes |


              | Microsoft
                DirectSound |
              Yes |


              | Microsoft
                DirectSound 3D & Derivatives |
              Yes |


              | PCI
                2.1 |
              Yes |


              | AC97 |
              Yes |


              | MPU-401
                UART |
              Yes |


              | Microphone
                In |
              Yes |


              | Line
                In |
              Yes |


              | Line
                Out (Front)/Speaker Out |
              Yes |


              | Line
                Out (Rear) |
              Yes |


              | MIDI/Joystick
                Port |
              NA |


              | MPC3
                CD Audio In |
              Yes |


              | Auxiliary
                In |
              NA |


              | S/PDIF
                In |
              Yes |


              | Telephone
                Answering Device (TAD) In |
              NA |


              | Live!Drive |
              Yes |


              | 4
                Speaker Support |
              Yes |


              | Live!Ware
                Upgrades |
              Yes |


              | Creative
                MultiSpeaker Surround |
              No |


              | Creative
                Environments |
              Yes |


              | Windows
                ME |
              Yes |


              | Dolby?Digital
                5.1 decoding |
              No |



           |


       |



 |
